Wāvtech thinPRO12 12” Professional Series Shallow Subwoofer

The Wāvtech thinPRO12 is a 12" professional-series shallow subwoofer designed for high-performance bass in tight vehicle spaces. With a 3" mounting depth and a patent-pending design, it delivers over 2 inches of peak-to-peak excursion and 20mm of linear xmax for controlled, deep bass in compact installations.

• 750 Watts RMS Power Handling: Demonstrates substantial continuous power capability, supporting strong bass output when paired with a capable amplifier.
• 3" Mounting Depth: Enables installation in unusually shallow spaces, such as under seats or compact cargo areas, without sacrificing performance.
• 5" Voice Coil: Provides a large coil diameter for improved thermal management and sustained power handling during demanding musical transients.
• 4-Layer Winding on Vented Polymide Composite Former: Enhances coil durability and heat dissipation, helping maintain performance under high excursion.
• FEA Optimized Dual-Gap Motor Structure: A massive motor with double stacked strontium magnets delivers high flux density and precise control for linear cone movement.
• 20mm Linear xmax: Indicates the cone can travel a significant distance in a straight line for deep bass with minimal distortion within the enclosure.
• Honeycomb Nomex® and Glass Fiber Cone: Combines strength and lightness for rigid, responsive cone behavior under high output.
• Double-Roll NBR Surround & Mirrored Internal NBR Spiders: Balanced suspension system that supports large excursions while maintaining stability and linearity.
• 8AWG Push Terminals: Heavy-duty connections designed for low resistance and reliable high-current wiring.
• Vented Cast Aluminum Frame: Rigid, thermally managed chassis that helps dissipate heat and withstand daily driving conditions.
• Dimensions: 11 1/8" (282 mm) Standard 12" Cutout: Fits common 12" mounting openings, simplifying installation compatibility.
• Sealed / Ported Enclosure Compatibility: Sealed enclosures 0.4–1.0 cu ft (optimum 0.6 cu ft); ported enclosures 0.8–1.5 cu ft (optimum 1.0 cu ft). Real-world box choice depends on desired bass response and space.
• Protective Grille (TP12G Sold Separately): Optional protection for the active cone in exposed installations.

In a real car audio build, the thinPRO12 excels in compact enclosures while delivering deep, controlled bass thanks to its large 5" voice coil, high excursion capability, and a motor system designed for tight, linear cone control. It suits small sealed or ported boxes and under-seat or trunk-side installs, providing reliable performance within the recommended enclosure sizes and offering robust electrical and mechanical hardware to support long-term everyday use.
