Jensen 815 Watts Class D 5-Channel Amp with Bluetooth App Control – JA5B
Jensen 815 Watts Class D 5-Channel Amp with Bluetooth App Control – JA5B is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Jensen 815 Watts Class D 5-Channel Amp with Bluetooth App Control –...
Description
Description
The Jensen JA5B 5-Channel MOSFET Amplifier delivers up to 815 Watts of dynamic power, engineered to drive full-range speakers and a subwoofer with high efficiency. Featuring advanced Class D circuitry, it ensures reliable performance and high-quality audio output within a compact footprint.
Integrated Bluetooth connectivity enables app-based control over RGB illumination and audio system configuration directly from compatible iOS and Android devices. Built with versatile 2-Ohm and 4-Ohm stability, adjustable high-pass and low-pass crossovers, and low-level RCA inputs, this amplifier provides precise tuning for any custom vehicle audio installation.
Key Features
| Weight | 2.7 kg |
| Dimensions (D x W x H) | 14.2 cm x 28.3 cm x 5.5 cm |
| Speaker Outputs | 5 |
| Amplifier Class | Class D |
| Max Dynamic Power | 815 W |
| CTA-2006-D Certification | Certified |
| Audio Inputs | Low Level (RCA) |
| Impedance Stability | 2 Ohm and 4 Ohm Stable |
| Illumination | RGB Customizable |
| Wireless Connectivity | Bluetooth App Control |
| Crossover | Adjustable High and Low-Pass Crossovers (32Hz – 320Hz) |
| Frequency Response | 20 Hz – 20 kHz, 20 Hz – 300 Hz |
| Power Supply | PWM MOSFET |
| Fuse Rating | 2 x 40A |
| Recommended Power/Ground Wire | 8 AWG |
| Recommended Speaker Wire | 12 AWG |
Highlights
- 5-Channel MOSFET amplifier with Class D design
- App control via Bluetooth for illumination and setup
- RGB customizable illumination
- 2 & 4 Ohm stable with adjustable crossovers
- Dynamic power output up to 815 Watts
- CTA-2006-D Certified
Compatibility
Compatible with vehicle audio systems utilizing low-level RCA inputs, 2-Ohm or 4-Ohm speaker configurations, and Apple or Android devices running the Jensen DSP Amp application.
Warranty
4-year limited warranty when registered within 60 days of purchase.Downloads
