Hifonics HCC525CX COLOSSUS Classic 5.25 Inch Coaxial Speakers
Description
Description
The Hifonics HCC525CX COLOSSUS Classic 5.25-inch 2-way coaxial car audio speakers deliver powerful, accurate sound reproduction. Featuring lightweight blue woven fiber cones paired with durable butyl rubber surrounds, they provide swift midrange response and impactful mid-bass performance.
High frequencies are handled by 1-inch aluminum dome tweeters engineered for natural audio detail and high output. An integrated passive Butterworth crossover ensures a seamless frequency transition between the midrange and tweeter elements.
Built on an anti-resonant stamped steel basket with an overcoil cooling system, these speakers maintain thermal efficiency and structural stability. Pure copper voice coils on Kapton formers ensure reliable power handling and heat dissipation across demanding listening sessions.
Key Features
| Brand | Hifonics |
| Model | HCC525CX |
| Series | COLOSSUS CLASSIC |
| Speaker Size | 5.25" |
| Speaker Type | 2-Way Coaxial |
| RMS Power Handling | 40 W |
| Peak Power Handling | 80 W |
| Impedance | 4 Ohms |
| Frequency Response | 80Hz-20kHz |
| Sensitivity | 88 dB |
| Crossover Slope | 6kHz 12dB |
| Mounting Diameter / Cut Out | 11.4 cm |
| Outside Diameter | 15.9 cm |
| Mounting Depth | 5.1 cm |
| Overall Dimensions | 30.5 × 16.8 × 8.1 cm |
| Weight | 1.7 kg |
| Cone Material | Woven Fiber |
| Surround Material | Butyl Rubber |
| Tweeter Size | 1" |
| Tweeter Material | Aluminum Dome |
| Magnet Type | Ferrite |
| Voice Coil Material | Copper |
| Former Material | Kapton |
| Basket Material | Stamped Steel |
| Color | Black / Blue |
| Vehicle Fitment | Universal |
Highlights
- 5.25-inch 2-way coaxial speaker configuration
- 40W RMS and 80W peak power handling at 4 ohms
- 1-inch aluminum dome tweeter with passive Butterworth crossover
- Lightweight woven fiber cone with durable butyl rubber surround
- Anti-resonant stamped steel basket with overcoil cooling
Compatibility
Designed for universal vehicle fitment in standard 5.25-inch factory speaker locations requiring a 11.4 cm cutout and 5.1 cm mounting depth.
