Diamond Audio 6"x9" 2-Way Coaxial Speaker w/Titanium Dome Tweeter (2Ω) - MS692CX2

Diamond Audio MS692CX2 — 6"x9" 2-Way Marine Coaxial Speaker with Titanium Dome Tweeter (2Ω)

The Diamond Audio MS692CX2 is the 2Ω variant of the MS69CX Coax-Sub platform, engineered for riders, boaters, and off-road enthusiasts running low-impedance amplifier systems who demand maximum output and full-range performance in harsh environments. Built to IPx65 marine-grade specifications, the MS692CX2 combines a UV-treated waterproof Kevlar cone, a 1" titanium dome tweeter, and Diamond Audio's "Coax-Sub" design to deliver deep bass extension, clear midrange, and crisp highs — all from a single speaker.

With a frequency response of 45Hz–23kHz and 130W RMS / 520W MAX power handling, the 2Ω impedance allows your amplifier to push more power for higher output and more aggressive performance. A 12dB Bessel crossover network ensures smooth frequency transitions, while the T-yoke back plate motor design improves cooling by 35% for sustained high-power reliability.

Key Features

• 2Ω impedance — maximizes amplifier output for louder, more aggressive performance
• IPx65 marine-grade construction — waterproof, UV-resistant, salt-resistant
• "Coax-Sub" design for enhanced low-frequency output without a dedicated subwoofer
• 1" high-output titanium dome tweeter for crisp, detailed highs
• UV-treated waterproof Kevlar cone with rubber surround for durability and tight bass
• 12dB Bessel crossover network for smooth, natural frequency transition
• Super high-energy ferrite motor with milled aluminum top plate for efficiency
• T-yoke back plate design improves motor cooling by 35%
• Cast aluminum basket for strength and vibration resistance
• Compatible with boats, ATVs, UTVs, motorcycles, and outdoor audio systems

Specifications

• Power Handling: 130W RMS / 520W MAX
• Impedance: 2Ω
• Frequency Response: 45Hz – 23kHz
• Sensitivity (1W/1M): 87.6dB
• Sensitivity (2.83V/1M): 94.6dB
• Voice Coil: 1.66" (42.2mm)
• Fs (Free Air Resonance): 46Hz
• Qts: 0.51
• Vas: 0.794 ft³ (22.5L)
• Xmax: 0.315" (8mm)
• Mounting Depth: 3.818" (97mm)
• Mounting Diameter: 5.98" x 8.85" (152mm x 225mm)
