Diamond Audio 5"x7" 2-Way Harley-Davidson® Direct Replacement Speakers (2Ω)- HXM57F2BK

Diamond Audio HXM57F2BK — 5"x7" HXMFB Series 2-Way Harley-Davidson Direct Replacement Speakers (2Ω)

The Diamond Audio HXM57F2BK is a 5"x7" 2-way coaxial speaker engineered as a true direct replacement for Harley-Davidson factory fairing locations. Part of the HXMF Black Series, the HXM57F2BK delivers class-leading output and clarity with a rigid carbon fiber cone, an ultra-light neodymium motor structure, and an oversized 1.25" titanium dome tweeter — producing 150W RMS with 91dB sensitivity in a flush or back-mount design that drops straight into factory cutouts with no modification.

The 2Ω impedance maximizes amplifier output for higher volume levels and improved clarity at highway speeds, while water spray and salt water resistance with 100% UV stability ensure long-term durability in demanding riding conditions.

Key Features

• Direct replacement for Harley-Davidson 5"x7" factory fairing speaker locations
• Rigid carbon fiber cone for increased output and accurate midrange reproduction
• Oversized 1.25" titanium dome tweeter for crisp, detailed highs that cut through wind noise
• Ultra-light neodymium motor structure with max Xmax suspension for efficiency and output
• 2Ω impedance — maximizes amplifier output for louder, more aggressive performance
• Flush or back-mount design for flexible, no-modification installation
• Water spray and salt water resistant, 100% UV stable
• High-temp lightweight injection-molded composite basket for durability

Specifications

• Power Handling: 150W RMS / 300W MAX
• Sensitivity: 91dB (1W/1M)
• Impedance: 2Ω
• Tweeter: 1.25" Titanium Dome
• Cone: Rigid Carbon Fiber
• Basket: High-Temp Injection Molded Composite
• Magnet: Neodymium
• Mount Style: Flush or Back Mount
• Mounting Depth: 2.55" (64.84mm)
• Cutout Diameter: 7.11" (180.72mm)
• Overall Diameter: 7.80" x 5.44" (198.21mm x 138.2mm)
• Overall Height: 3.11" (78.87mm)
• UV Stability: 100% UV Stable
• Water Resistance: Water Spray & Salt Water Resistant
