Trinity Audio Single M Series 12" Subwoofer & 2000.1v2 2,000 Watt Monoblock Amplifier

The Trinity Audio Single M Series 12" Subwoofer & 2000.1v2 2,000 Watt Monoblock Amplifier is built for bass enthusiasts who demand deep, high‑output low end with reliable heat management in a 12" package.

• RMS Power (Sub): 2,000 Watts RMS with bursts up to 6,000 W; tested performance supports bursts up to 18,000 W without damage. This means strong, clean peaks are possible without clipping or thermal failure during demanding playbacks.
• 650 oz Double‑Stacked Ferrite Motor: Provides substantial magnetic force for deep bass and high excursion, while the dual stacks help control distortion at high output for cleaner low end.
• FEA‑Optimized Construction: Finite Element Analysis applied to the motor and basket structure to maximize rigidity and heat dissipation, reducing flex under power and sustaining performance under long sessions.
• Triple‑Layer Foam High‑Excursion Surround: Durable, flexible surround that supports large cone movement and quick recovery, enabling tighter bass control at high power.
• Rigid Composite Paper Cone: Combines stiffness and lightness to reproduce accurate bass across the frequency spectrum with minimal cone cry and coloration.
• 10" Quad‑Layer Progressive Nomex Spider Pack: Advanced spider design improves linearity and stability of the suspension under heavy excursion, helping maintain consistent bass output.
• 3" BASV High‑Temperature Dual Voice Coil: Handles heat from sustained power, preserving impedance and excursion consistency during extended sessions.
• Enclosure Flexibility: Optimized for both ported and bandpass enclosures, giving installers multiple bass personalities from the same driver.
• Recone Options & 1‑Year Warranty: Availability of recone parts supports long‑term value, backed by a manufacturer warranty for peace of mind.
• Key Physical & Electrical Metrics: Outer Diameter 12.8", Cutout 11.22", Mounting Depth 8.58", Displacement 0.25 ft3. Coils measure 3" x 55mm with a 4ga terminal; Ferrite Grade Y35; Dual‑coil variants (M12 D1 and M12 D2) present slightly different electrical and mechanical targets to suit different enclosure alignments.

In a real car audio build, this sub excels in high‑power applications where deep, controlled bass is the priority. The robust motor and heat‑dissipation features support sustained play in both daily listening and competition contexts, while the enclosure options let you tailor low‑end behavior to your space. Recone availability and a 1‑year warranty add practical long‑term value for serious bass projects.
