Trinity Audio Single M Series 10" Subwoofer & 2000.1v2 2,000 Watt Monoblock Amplifier
Trinity Audio Single M Series 10" Subwoofer & 2000.1v2 2,000 Watt Monoblock Amplifier - Yes - I'm Fearless & Want To Be LOUD! is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Description
Description
The Trinity M Series 10" Subwoofer delivers 2,000 Watts RMS in a compact 10" package, built for bass enthusiasts who demand high-output, low-distortion low-end and reliable performance under demanding use. Featuring a triple-stacked ferrite motor (650 oz) and optimized airflow, it is engineered for deep, controllable bass in both daily and competitive car audio setups.
- Power handling: 2,000 Watts RMS supports sustained high-output bass without immediate compression or heat-induced sag, enabling louder, more capable systems.
- Motor system: Triple-stacked ferrite motor (650 oz) provides strong magnetic pull for deep bass and reduced distortion at high excursion in demanding listening sessions.
- Voice coil: 3" BASV high-temperature dual voice coil handles elevated temperatures, helping maintain consistent performance during long, heavy bass plays.
- Spider pack: 8" quad-layer progressive Nomex spider pack keeps the coil centered under heavy movement, improving linearity and durability as power increases.
- Surround: Triple-layer foam high-excursion surround accommodates large cone travel while preserving control and reliability.
- Cone: Rigid composite paper cone delivers precise bass reproduction with solid stiffness for accurate response across the frequency range.
- Ventilation and heat management: Optimized airflow system facilitates heat dissipation for extended operation at high power levels.
- Enclosure compatibility: Suitable for both ported and bandpass enclosures, offering flexibility in how you shape bass output to your vehicle and preferences.
- Recone options and warranty: Recone options are available and the product includes a 1-year manufacturer warranty, underscoring Trinity Audio Solutions' commitment to longevity.
- Physical dimensions: Outer Diameter 10.85", Cutout Diameter 9.25", Mounting Depth 7.75" for fitment planning in sealed or vented enclosures.
In a real car audio build, this sub excels in deep, defined bass with minimal distortion at elevated power levels. Its dual-voice-coil configuration options, robust motor, and heat-management design make it a solid foundation for both daily bass lovers and competitive setups, while recone availability and warranty add long-term reliability to your system.
| Driver | M10 D1 | M10 D2 |
| FS | 36.9 Hz | 33.6 Hz |
| Re | .95 Ω +.95 Ω | 1.9 Ω + 1.9 Ω |
| Qms | 6.67 | 6.87 |
| Qes | 0.45 | 0.38 |
| Qts | 0.42 | 0.36 |
| Mms | 294.7 g | 325.2 g |
| Cms | 0.07 mm/N | 0.06 mm/N |
| Sd | 47.2 in2 | 47.2 in2 |
| Vas | 8.2 L | 9.0 L |
| Spl | 87.6 dB | 81.3 dB |
| BL | 17.4 | 26.1 |
| X-max | 25mm | 25mm |
| Outer Diameter | 10.85 in | 10.85 in |
| Cutout Diameter | 9.25 in | 9.25 in |
| Motor Diameter | 9.05 in | 9.05 in |
| Mounting Depth | 7.75" | 7.75" |
| Displacement | .17 ft3 | .17 ft3 |
| Coil Dimensions | 3" x 55mm | 3" x 55mm |
| Coil Wire | Black CCA | Black CCA |
| Ferrite Grade | Y35 | Y35 |
| Terminal Wire Gauge | 4ga | 4ga |
| RMS Power | 2,000 | 2,000 |
| Burst Power | 6,000 | 6,000 |
| MODEL | 2000.1v2 |
| RMS @ 4 Ohms | 720 Watts |
| RMS @ 2 Ohms | 1100 Watts |
| RMS @ 1 Ohm | 2000 Watts |
| Total Harmonic Distortion | <.02% |
| Signal To Noise Ratio | 94db |
| Frequency Range | 10 Hz - 20,000 Hz |
| Signal Input Range | .4 - 7 VAC |
| DC Voltage Input Range | 9-16.5 VDC |
| Measurements In. (L x W x H) | 8" x 7.5" x 2.5" |
