Trinity Audio Single E Series 10" Subwoofer & 1000.1v2 1,000 Watt Monoblock Amplifier

The Trinity E Series 10" Subwoofer, paired with the Trinity Audio Solutions 1000.1v2 1,000 Watt monoblock amplifier, is engineered for value-minded bass enthusiasts who want deep, controlled low-end without upgrading their electrical system. It delivers 800W RMS (2400W peak) and combines a gunmetal stamped basket with a 3" high-temperature dual voice coil and a double-stacked motor for durable, high-output performance.

• RMS Power: 800W continuous power handling for sustained bass output without strain.
• Burst Power: 2,400W peak handling to reproduce short, dynamic transients in music or film scores.
• Impedance Options: Dual 2-ohm and dual 4-ohm configurations, providing flexible wiring to match multiple amplifiers.
• Voice Coil & Motor: 3" high-temperature dual voice coil and a double-stacked motor for improved heat handling and consistency during high excursion.
• Cooling & Design: Finite Element Analysis (FEA)–tuned motor cooling for stability across extended listening sessions.
• Enclosure Compatibility: Performs best in ported, 4th order, or 6th order bandpass enclosures to maximize bass output and efficiency.
• Key Dimensions & Displacement: Outer diameter 10.3 in; Cutout 9.05 in; Mounting depth 6.2 in; Displacement 0.15 ft³.
• Performance Metrics: SPL 85.2 dB (D2) / 85.5 dB (D4); BL 18.8 (D2) / 21.6 (D4); X-max 15 mm; Sd 51.1 in²; Vas 11.9 L.
• TS Parameters: Re 1.9 Ω + 1.9 Ω (D2) / 3.2 Ω + 3.2 Ω (D4); Qms 5.94 (D2) / 6.21 (D4); Qes 0.62 (D2) / 0.71 (D4); Qts 0.56 (D2) / 0.64 (D4); Mms 292 (D2) / 242.7 (D4); Cms 0.08; Coil Dimensions 3" x 40mm; Coil Wire 8ga.
• Warranty & Recones: 1-year manufacturer warranty with recone kits available for long-term value.

Benefits: In a typical build, this 10" driver excels in budget-conscious installations where deep, resonant bass matters. The dual-impedance options and 0.15 ft³ displacement offer flexible enclosure decisions, while the 3" voice coil and FEA-optimized cooling enable reliable performance during extended play. Paired with the 1000.1v2 amp, it suits ported or bandpass configurations to extract substantial bass from a compact footprint, backed by a solid warranty and available recone support.
