DC Audio Pro Audio 12pt NEO Bullet Super Tweeter

The DC Audio Pro Audio 12pt NEO Bullet Super Tweeter is a compact, high-efficiency tweet built for premium car audio systems. It delivers extended top-end clarity and fast transient response at highway and urban listening levels.

• Power Handling: 60W RMS / 120W MAX — means it can sustain continuous playback at 60 watts and tolerate brief peaks up to 120 watts without stress, giving you headroom in dynamic passages.
• Impedance Options: 4 Ω or 8 Ω — provides flexibility to match your amplifier and crossover design for optimal power transfer and loading.
• Voice Coil: 1" voice coil — a larger coil helps maintain control at high frequencies and supports better thermal handling in demanding use.
• Former Material: CCAW — a lightweight, rigid former that supports precise coil alignment for consistent high-frequency performance.
• Diaphragm Material: Titanium — offers stiffness and fast response, contributing to clean, crisp high-frequency extension with minimal distortion.
• Magnet: Neodymium — provides strong magnetic flux in a compact form, aiding efficiency and compact installation.
• Frequency Response: 1.5 kHz – 20 kHz (includes passive crossover 100V 2.2µF) — covers the critical high-frequency range with an integrated crossover to protect the tweeter and define the crossover point.
• Sensitivity: 100 dB — high efficiency means more output from less input, helping achieve audible top-end with moderate amp power.
• Cutout: 1.7" — necessary for precise mounting in dashboards or panels with a standard small-tweeter opening.
• Mounting Depth: 1.35" — shallow depth allows installation in tighter spaces without sacrificing performance.
• Total Depth: 2.00" — overall depth to consider when planning enclosure or dash fitment.
• Sold In: Pairs — shipped as a matched pair for symmetrical left/right installation.

In a premium car audio build, this tweeter delivers clear, detailed high-frequency output with fast transients. The combination of a titanium diaphragm, neodymium magnet, and a 1" voice coil provides precise control at audible extremes, while the included passive crossover simplifies integration and protects the driver from overextension.
