Stetsom BRAVO BASS 5K Digital Subwoofer Amplifier Mono 1 Channel Class D 5000 Watts RMS

The Stetsom BRAVO BASS 5K is a 1-channel mono Class D subwoofer amplifier delivering up to 5200W RMS at 1 Ohm (14.4V), built for serious bass-focused installations where one high-power output matters. Its compact chassis pairs power with precise bass control for demanding subwoofer applications.

• 1-Channel Mono Class D design: Dedicated single-channel output optimized for subwoofer duty, simplifying wiring and delivering focused bass.
• RMS Power at 1 Ohm: 5200W (14.4V) — extreme bass capability when driven into a 1 Ω load.
• RMS Power at 2 Ohm: 2900W (14.4V) — substantial headroom for mid-to-high bass applications with a higher impedance load.
• Supply Voltage: 9V ~ 17V DC — wide operating range compatible with typical automotive electrical conditions.
• Frequency Response (Flat On): 5 Hz ~ 600 Hz — flat response across the sub-bass to low-bass range when FLAT ON is engaged.
• Frequency Response (Flat Off): 5 Hz ~ 250 Hz — adjusted response when FLAT OFF, suitable for targeted bass tuning.
• Crossover Low Pass: 30 Hz ~ 250 Hz — restricts signal to sub-bass frequencies, reducing muddiness from higher tones.
• Subsonic Filter: 5 Hz ~ 40 Hz — removes ultra-low frequencies to protect the sub and improve control.
• Bass Boost: 0 ~ +10 dB (30 Hz ~ 70 Hz) — adds low-end presence when desired without altering the entire spectrum.
• Signal to Noise: >90 dB — low noise floor that helps maintain clarity at high output settings.
• Input Impedance: 4.8K Ohms — compatible with common source gear for clean signal transfer.
• Dimensions (H x W x L): 3.14" x 9.11" x 13.11" — compact footprint suitable for tight installs.
• Weight: 9.50 lbs — manageable for a high-power mono amp in a vehicle environment.
• Musical Consumption: 228A
• BASS Consumption: 456A

Benefits: In a real car audio build, this amplifier serves as the dedicated subwoofer power module, delivering high wattage from a compact form factor. The integrated low-pass and subsonic filters enable precise bass shaping, while the bass boost option lets you tailor low-end presence to your cabin acoustics. The 9–17V operating range accommodates typical vehicle electrical conditions, and the 1 Ohm rating with substantial wattage provides headroom for dynamic bass bursts without compromising efficiency. Its compact size and weight simplify installation in trunks or under seats, making it a strong choice for a single-driver sub-focused setup seeking clean, powerful low end.
