Hifonics ZS35CX ZEUS 3.5 Inch Speakers
Description
Description
The Hifonics ZS35CX ZEUS 3.5-inch 2-way coaxial car audio speakers deliver clear highs and responsive sound in a compact design. Engineered with a 1-inch Neo-Mylar soft dome tweeter and an Alpha-Cellulose poly woofer cone, this speaker pair provides dependable high-frequency reproduction and rigid bass performance.
Built for resilience and thermal efficiency, these speakers feature a moisture-resistant rubber surround, Kapton voice coil former assembly, and an overcoil cooling system. The epoxy-infused natural fiber spider and anti-resonant stamped steel basket minimize mechanical distortion for clean audio delivery.
Equipped with a ferrite motor and passive Butterworth crossover, the system ensures seamless frequency transitions between midbass and treble. Designed for universal vehicle compatibility, they easily integrate behind existing OEM door and dashboard panels using direct solder or standard spade connections.
Key Features
| Brand | Hifonics |
| Series | ZEUS |
| Product Type | Coaxial Speaker |
| Speaker Size | 3.5" |
| RMS Power Handling | 25 W |
| Peak Power Handling | 125 W |
| Impedance | 4 Ohms |
| Frequency Response | 80Hz - 20kHz |
| Sensitivity | 88 dB |
| Crossover Slope | 6kHz 12dB |
| Tweeter Size | 1" |
| Tweeter Material | Neo-Mylar Soft Dome |
| Cone Material | Alpha-Cellulose Poly |
| Surround Material | Rubber |
| Basket Material | Stamped Steel |
| Mounting Depth | 3.8 cm |
| Mounting Diameter | 8.7 cm |
| Overall Dimensions | 24.8 × 15.2 × 7.3 cm |
| Weight | 0.9 kg |
| Color | Black |
| Compatible Vehicles | Universal |
Highlights
| Feature | Benefit |
|---|---|
| Tweeters | 1 inch: Clear highs while handling plenty of power without sound harsh. Neo-Mylar Soft Dome Tweeter: Impact Resistant Tweeter Elements, Great sound quality and increased reliability. Kapton: Lightweight and efficiently dissipates heat. |
| Cone Material | Alpha-Cellulose Cones: Light weight for speed and very rigid for deep bass. |
| Surround / Cone Coupling | Rubber: Moisture Resistant Rubber Surround with high Mid-Bass Impact. High Temperature Adhesive: Special adhesive is chosen to create a permanent bond between the cone and the surround. |
| Voice Coil / Former Assembly | Pure Copper: Creates strong magnetic field with a very thin extrusion. Kapton: Lightweight and efficiently dissipates heat. |
| Spider | Epoxy infused Natural Fiber: Natural fiber allows flexibility while the epoxy which gives strength during the manufacturing process. |
| Cooling System | Overcoil: Air is exchanged over the voice coil through the spider. |
| Crossover | Passive Butterworth: Smooth transition of frequencies from midrange/midbass to the tweeter element. |
| Frame | Anti-Resonant Stamped Steel Basket: Very strong with minimal harmonics or distortions from flex or ringing. |
| Motor | Ferrite Magnet: Creates a strong magnetic field while remaining small enough to fit nearly every application. |
| Connectors | Spade: Use spade connectors or solder direct for the best connection. |
| Grills | No: These speakers are typically installed behind an OEM panel. |
Compatibility
Designed for universal vehicle fitment in locations accepting 3.5-inch speaker drivers behind OEM factory panels with a mounting depth of 3.8 cm.
Warranty
- 1 Year manufacturer's warranty
