Hifonics HSP-4.8DSP 2 or 4 Input / 8 Output Digital Signal Processor

Name: Hifonics HSP-4.8DSP 2 or 4 Input / 8 Output Digital Signal Processor
Brand: Hifonics
SKU: 806576238294
Price: 199.99 USD
Availability: InStock

$199.99 $239.99

Description

The Hifonics HSP-4.8DSP 2 or 4 Input / 8 Output Digital Signal Processor integrates seamlessly with OEM and aftermarket car audio systems. It delivers precision acoustic calibration through high-level inputs and nickel-plated RCA connections.

Featuring a 31-band parametric equalizer, fully adjustable crossovers, and delay timing alignment, this unit allows total acoustic control directly from an iOS or Android device. High-resolution 32-bit processing running at a 96kHz sampling frequency ensures clean, uncompromised audio reproduction across the entire frequency range.

Equipped with selectable internal loading resistors, an external Bluetooth antenna, and an input clip indicator light, this processor offers versatile integration into universal vehicle configurations.

Key Features

Brand	Hifonics
Series	HSP
Product Type	Digital Signal Processor
Inputs	2 or 4
Outputs	8
Weight	0.7 kg
Dimensions	17.1 × 11.5 × 4 cm
Package Dimensions	25.4 × 14.6 × 7 cm
Color	Black
Condition	New
Bit Rate	32-bit
Sampling Frequency	96kHz
Equalizer	31 Band Parametric EQ
High Level Input Voltage	4V to 40V
RCA Low Level Input Voltage	4V to 12.5V
RCA Pre-out Voltage	4V Max
Signal to Noise Ratio	> 80dBA
Channel Separation	> -55dB
Selectable Loading Resistors	20 ohm / 60 ohm
Software Compatibility	Android App and Apple App
Vehicle Fitment	Universal

Highlights

Feature	Details
Compatible Vehicle Fitment	Universal
Installation	High Level Inputs allow for integration into OEM audio systems that do not offer RCA outputs. Four high temperature impact resistant nickel-plated RCA inputs allow for connection into aftermarket audio systems.
Other Features	2 or 4 Input / 8 Output Digital Signal Processor; 31 Band Parametric EQ; Fully Adjustable Crossovers; Delay Timing Alignment; High Level Input Voltage: 4v to 40v; RCA Low Level Input Voltage: 4v to 12.5v; RCA Pre-out Voltage: 4v Max; Signal to Noise Ratio: > 80dBA; Frequency Response: -55dB; Bit Rate: 32bit; Sampling Frequency: 96kHz; Selectable Loading Resistors Built In: 20 ohm / 60 ohm; External Antenna for Enhanced Bluetooth Signal Reception; Input Clip Light Indicator; Tuning Operating Software: Android App and Apple App; Dimensions: 6.73” x 4.53” x 1.57”

Compatibility

Universal compatibility with OEM and aftermarket car audio systems. Tuning software is compatible with Apple iOS and Android mobile devices.

What's included

Hifonics HSP-4.8DSP Digital Signal Processor
Mounting Hardware
External Bluetooth Antenna

Downloads

Hifonics HSP4.8DSP Manual (Rev1)

Frequently asked questions

How do you control and tune the HSP-4.8DSP?

System tuning and acoustic adjustments are handled wirelessly via the dedicated operating software app available for Apple iOS and Android devices.

Can this processor connect to a factory OEM radio?

Yes, it includes high-level inputs capable of handling 4V to 40V, allowing direct integration into factory audio systems without RCA outputs.

What audio processing features are included?

The processor provides a 31-band parametric equalizer, fully adjustable crossovers, delay timing alignment, and 32-bit / 96kHz digital processing.

What vehicle models are compatible with this processor?

The unit features universal vehicle compatibility for both OEM and aftermarket car audio setups.
