Hifonics BRL3000.1 BRUTUS BRL 3000 Watt Mono Block Amplifier
Description
Description
The Hifonics BRUTUS BRL3000.1 is a high-performance Super D Class mono block amplifier engineered to deliver up to 3000 watts of RMS power. Built with an ultra-high efficiency half-bridge design and Ultra-Fi MOSFETs, it ensures maximum power output and reliable thermal dissipation.
A mass-loaded extruded aluminum heat sink and multi-layer PCB construction maintain low operating temperatures and minimal electromagnetic interference. Integrated stylized badging functions as an active VU meter for precise gain adjustment or can be set to solid illumination.
Advanced protection circuits guard against voltage spikes, short circuits, overcurrent, and thermal overload. An included wired bass remote provides straightforward output level adjustments directly from the driver seat.
Key Features
| Brand | Hifonics |
| Series | BRUTUS BRL |
| Model Number | BRL3000.1 |
| Type | Amplifier |
| Color | Black |
| Amp Class | Super D Class™ |
| Amp Total Channels | 1 |
| Amp Max Power (watts) | 3000 |
| Amp Power @ 1 Ohm (ch x watts) | 1 x 3000 |
| Amp Power @ 2 Ohms (ch x watts) | 1 x 2000 |
| Amp Power @ 4 Ohms (ch x watts) | 1 x 1300 |
| Amp Crossover | Variable Electronic 12dB Per Octave |
| Amp Variable High Pass Crossover 12dB per Octave | 15Hz-1KHz |
| Amp Variable Low Pass Crossover 12dB per Octave | 50Hz-10KHz |
| Amp Bass Boost | 0-12dB |
| Amp Variable Voltage | 0.2-9V |
| Amp Signal to Noise | 101dB |
| Amp Frequency Response | 10Hz-10kHz |
| Amp Total Harmonic Distortion (THD) | < 0.5% |
| Amp Power Terminal 12v/GND | 2 AWG |
| Amp Speaker Terminal Wire Gauge | 12 AWG |
| Amp Fusing | External 300A |
| Dimensions | 30.5 × 14.6 × 5.7 cm |
| Weight | 2.6 kg |
| Package Dimensions | 41.6 × 18.7 × 9.2 cm |
| Package Weight | 3.1 kg |
| Compatible Vehicles | Universal |
Highlights
| Feature | Description |
|---|---|
| Ultra-High Efficient Design | A power supply design coupled with carefully selected parts results in an ultra-high efficient amplifier. |
| Half Bridge Design | An efficient design with fewer components results in higher power output. |
| Ultra-Low EMI Design | Minimal interference with other vehicle electronic systems. |
| Mass-Loaded Heat Sink | The mass-loaded extruded aluminum heat sink results in improved thermal management and output performance. |
| High-End Preamplifier Circuit | Accepts a wider range of input signals. |
| RCA Inputs | Nickel-plated RCA jacks create an efficient connection that is corrosion-resistant. |
| High Tolerance Output Device | Ultra-Fi MOSFETS are designed for high output power and thermal dissipation through a proprietary coupling method. |
| Operation Mode | Mono only |
| Clean Board Construction | Multi-layer printed circuit boards (PCB) with surface mount components require fewer parts and result in a cleaner design. |
| Class / Topology | BRL amplifiers feature a Class-D chipset, providing efficiency and a wide frequency range. |
| Power Supply | Iron core transformer assists in the ultra-low EMI design while providing high power. |
| Delayed Turn-On Function | Ensures compatibility with a wide range of source units to eliminate unwanted turn-on/off noises like hisses and pops. |
| Connection Type | Secure molded connection terminal for all Power, Ground and Speaker connections. Angled for ease of access while creating a clean wire management profile. |
| Stylized Badging | Switch between full constant blue LED lights, VU Meter mode, or full off. When switched to VU Meter mode, the amplifier’s logo reflects the audio level, useful for gain adjustment. |
| Triple Protection Circuits | Over/under voltage, short circuit, overcurrent, and thermal protection circuits are built-in to protect the audio system and vehicle. |
| Bass Remote Included | The included bass remote on mono models allows adjustment of the bass level relative to the setting on the amplifier’s end panel. The LED indicator light displays green when the amplifier is powered on and red if the amplifier enters protect. |
Compatibility
Universally compatible with 12V automotive electrical systems and standard aftermarket source units and subwoofers.
What's included
- Hifonics BRUTUS BRL3000.1 Mono Block Amplifier
- Bass Remote Control with Cable
