DS18

DS18 EXL-SQ4.0 EXL 4" 2-Way Coaxial Speaker with Fiber Glass Cone 340 Watts 3-Ohm

Sale price $119.99 Regular price $129.99
Shipping calculated at checkout.

Highlight title

Text to highlight a key feature of your product

Description

DS18 EXL-SQ4.0


Glass Fiber 4" 2-Way Coaxial Car Speaker 560 Watts 3-Ohm

Instantly increase the sound quality in your car and get EXTREMELY LOUD with powerful clear sound that fills any space using DS18’s EXL-SQ4.0.

The 2-way design of the EXL-SQ4.0 equips it with both a woofer and a tweeter, which work together to produce a full and dynamic sound. These speakers are capable of reproducing both high and low frequencies with remarkable accuracy. From soaring vocals to deep, thumping bass lines, you'll hear every nuance and detail of your favorite songs.

The EXL-SQ4.0 has a 2-way design with a 3-ohm impedance, making these speakers extremely easy to incorporate into any high-powered audio system.

The glass fiber cone equipped on the EXL-SQ4.0 guarantees it performs at it’s best and has a longer lifespan. The glass fiber cone provides stiffness, ensures accurate sound reproduction, and minimizes distortion. It’s lightweight design enables faster and more responsive changes to the signal, while also maximizing energy efficiency.

One of the key features of the EXL-SQ4.0 is its advanced engineering, which has been carefully optimized to ensure maximum sound quality and clarity. Every component, from the advanced PEI dome tweeter to the neodymium magnets, and black glass fiber cone has been carefully chosen and tuned to deliver the best possible audio performance. This attention to detail ensures that every note, every beat, and every detail of your music is reproduced with incredible accuracy and fidelity.

SPECS

SKU
EXL-SQ4.0
Nominal Diameter
4" / 101.6mm
Nominal Impedance
3 ohm
RMS Power Handling
60W
MAX Power Handling
260W
Sensitivity (1w/1m)
85 dB
Frequency Response
115Hz - 22KHz
Recommended HI Pass Crossover
140Hz
Number of ways
2-way
Pair or Single
Pair
Grill Included
Yes


WOOFER SPECIFICATIONS

Voice Coil Diameter
1"/ 25.5mm
Voice Coil Former Material
BASV
Winding Material
CCAW
Cone Material
Glass Fiber
Surround Material
Rubber
Basket Material
Aluminum
Basket Color/Finish
Granite Silver
Magnet Material
Strontium
Magnet Weight
9 Oz


THIELE & SMALL PARAMETERS

Equivalent Volume Vas
1.2L / 0.043ft3
Free Air Resonance Fs
113Hz
DC Resistance Re
2.8 ohm
Mechanical Factor Qms
4.889
Electrical Factor Qes
0.873
Total Factor Qts
0.741


TWEETER SPECIFICATIONS

Nominal Diameter
0.8" / 20.3mm
Voice Coil Diameter
0.5" / 13mm
Diaphragm Material
PEI Dome
Magnet Material
Neodymium


SPEAKER MEASUREMENT

Overall Diameter
4.12" / 104.8mm
Overall Depth
2.14" / 54.5mm
Front Mount Baffle Cutout
3.77" / 96mm
Mounting Depth
1.96" / 50mm
Motor Diameter
3.14" / 80mm
Gross Single Unit Weight (lb)
4
Dimensions W x L x H (Inches)
12.5 x 6.25 x 3.5
Quantity of Units in Master Carton
10
Gross Master Carton Weight (lb)
39.5
M/C Dimensions W x L x H (Inches)
18.75 x 13.25 x 13
